Code: HI5-2764


Product Code: HI5-2764 (68)

Product Benefits

  • Formulated to handle extremes of operating temperatures
  • Provides a long trouble free service life and will be chemically stable under severe operating conditions
  • Ensures excellent filterability with hydrolytic and demulsibility stability


Hi-Tec XHVI ZF Hydraulic Oils meet or exceed the requirements of:

  • Vickers I-286-S, M-2950S; VDMA 24318;
  • Denison HF-1, HF-2, HF-0; SS 155434;
  • Cincinnati Milacron P-68, P-69, P70; ISO 6743/4 (HM, HV);
  • DIN 51524, Part 2 and 3; US Steel 127, 136;
  • SEB 181 222; AFNOR N FE 48-691 (wet);
  • AFNOR NFE 48 603 (HM, HV); ASTM-D2619 HF-0;
  • Other commercial hydraulics.

*Also available ISO *Also available ISO 15, 22, 32, 46, 68 and 100

In Stock


XHVI ZF Hydraulic Oils are specialised premium zinc free hydraulic fluids which have been formulated to handle the extremes of operating temperatures, pressures, power densities and fluid flow rates which are associated with very high horsepower hydraulic systems. These oils provide unique, long life operating service characteristics by a combination of anti-wear, detergent and very shear stable viscosity improving additives with proven rust, oxidation, corrosion and foam inhibitors. XHVI ZF Hydraulic Oils ensure excellent filterability with hydrolytic and demulsibility stability.

The anti-wear additives in XHVI ZF Hydraulic Oils ensure special protection where inherently high pressures, power densities and temperatures are experienced with high horsepower hydraulic pumps operating at pressures up to 48,000 kPa (7000 psi). These oils allow hydraulic systems to provide long, trouble-free service when operating with this increased horse-power, increased temperatures, reduced oil reservoir volumes and resultant reduced de-aeration times. XHVI ZF Hydraulic Oils possess excellent filterability even in the presence of moisture contamination; whereas other lubricants may have deposition products (formed as a result of hydrolytic instability particularly with non-ferrous hydraulic components) which plug filter systems leading to pump starvation, cavitation and ultimately premature equipment wear and failure. XHVI ZF Hydraulic Oils are multi-grade oils which have smaller viscosity changes with temperature variations than the more conventional fluids. At the very high operating temperatures experienced in high horsepower hydraulic systems, this property results in improved full-bodied, wear reducing, lubricant films compared to the thinned-out fluidity of the more conventional hydraulic fluids. This special viscosity control property is maintained by the very shear stable viscosity improver (VI) incorporated in XHVI ZF Hydraulic Oils, when other lesser VIs would shear down to less wear-protecting thinned-out fluids shortening the life of the hydraulic equipment.

XHVI ZF Hydraulic Oils have multi-metal compatibility with the ability to control wear and corrosion of copper and aluminium alloys used in high performance pumps. Corrosion inhibitors and metal passivators formulated in these fluids prevent corrosion of steels and the previously mentioned more easily attacked metals in severe operating service conditions.  XHVI ZF Hydraulic Oils are recommended for use with silver components as found in Lucas PM pumps and are suitable for circulating systems, bearings, general purpose lubrication and enclosed gear sets.

Additional information

Product Name


Manufacturer's Product Code

HI5-2764 (68), HI5-2762 (46), HI5-2759 (32)


Mineral oil based hydraulic fluid

Chemical Characteristics





, , ,
