TRANS SAE 60

Code: HI3-2520

TRANS SAE 60

Product Code: HI3-2520

Product Benefit

  • A specialised Transmission and Drive Train Oil (TDTO)
  • Meets the special requirements of the Caterpillar TO-4 and Allison TES-439 specifications.
  • Reduces gear wear, improves friction control, promotes long life in transmission and brakes



Hi-Tec Trans SAE 30 is suitable for the following applications:

  • Caterpillar TO-4, TO-2 and TO-4M
  • Komatsu Dresser and KES 07.868.1  (SAE 10W and SAE 30) powertrain fluid
  • Dana Powershift (SAE 10W and SAE 30)
  • Allison C-4 and Allison C-3 (SAE 10W and SAE 30) and TES-439
  • API: GL-3 • API: GL-4 and MT-1
  • API: CF in case of misapplication as an engine oil)
  • ZF TE-ML-03C (SAE 10W and SAE 30)
  • ZF TE-ML-07D (TO-4M only)
  • ZF TE-ML-07F (SAE 30)
  • Eaton (SAE 50)
  • Vickers 35 VQ25 and M-2950-S
  • Tremec/TTC (SAE 50)
  • Spicer Clark-Hurth (SAE 10W and SAE 30)



In Stock

Description

Hi-Tec TRANS SAE 60 is a specialised Transmission and Drive Train Oil (TDTO) which has been formulated to meet the special requirements of the Caterpillar TO-4 and Allison TES-439 specifications.
Hi-Tec TRANS SAE 60 greatly reduces gear wear, improves friction control, promotes long life in transmission and brakes, and ensures less brake noise and increased rimpull.
Hi-Tec TRANS SAE 60 is not a compromise fluid as are conventional powershift fluids, which are fundamentally engine oils meeting the former less restrictive CAT TO-2™ and Allison C-3 specifications.
CHARACTERISTICS
CONTROLLED FRICTION PERFORMANCE. The individual additive components of Hi-Tec TRANS SAE 60 were specially selected to balance and control the friction performance of the materials comprising the metallic and the newer non-metallic clutch surface materials.
STABLE FRICTION CHARACTERISTICS. The frictional properties uniquely provided by Hi-Tec TRANS SAE 60 overcome problems of excessive brake noise, weakening of the binders in paper surface materials and embrittlement of elastomeric materials. Hi-Tec TRANS SAE 60’s stable friction properties eliminate clutch slippage even under heavy loads on steep inclines. There is no need to constantly adjust equipment to maintain clutch settings.
OXIDATION STABILITY. The excellent anti-oxidation properties of Hi-Tec TRANS SAE 60 together with the resistance to sludge formation provide longer oil drain intervals and far more reliable equipment operation.
LOWER TEMPERATURE PERFORMANCE. The low temperature fluidity of Hi-Tec TRANS SAE 60 ensures easier cold weather starting and improved wear protection with low temperature startups.
ANTI-WEAR PROPERTIES. Long term anti-wear protection to gears and bearings is assured by the inclusion of special anti-wear additives. The foam inhibitors in Hi-Tec TRANS SAE 60 provide effective protection against foam development thus avoiding metal-to-metal contact and further minimising wear.
CORROSION PROTECTION. Long term rust and corrosion protection to steel and copper based metal is assured by the inhibitors in Hi-Tec TRANS SAE 60.
RECOMMENDATIONS
Hi-Tec TRANS SAE 60 is recommended for many heavy duty transmissions and drives in a wide range of automotive, mining, agricultural and earthmoving applications and particularly:
Caterpillar™ Transmissions
Hi-Tec TRANS SAE 60 meets the Caterpillar TO-4™ performance specifications and may be used in manual transmissions which have the API-CD/Caterpillar TO-2™ oil recommendation.
Hi-Tec TRANS SAE 60 transmission fluid is the ideal product for Final Drives: Track type: tractors, pipe-layers, skidders, loaders and track excavators Wheel Type: tractors, loaders, skidders, compactors, motor graders, off-highway tractors and trucks.



Additional information

Product Name

HI-TEC TRANS SAE 60W

Manufacturer's Product Code

HI3-2520

Use

Transmission Fluid

Chemical Characteristics

Liquid

Appearance

Amber
